Partite® Acrylic Adhesives No-Mix Structural Adhesive
System
|
Back |
|
PARTITE adhesives are no mix, two-part
system. Simply apply adhesive to one surface, the activator to
the other and join parts together. Fixture time will range from
60 seconds to 5 minutes depending upon the grade.
Following are the most popular grades with
specifications. Custom formulations and variety of packing are
available. |
|
|
|
|
Product |
Color |
Viscosity,
cps |
Cure
Speed |
Shear
Strength
(psi) |
Temperature
Range |
Activator |
Application |
|
9312
 |
Amber |
1,000 |
Fixture 30 sec
Full 24 hrs |
3,000 |
-65 °F
to
225 °F |
1387 / 1380 |
High strength structural adhesive
ideally designed for automotive rearview mirror bonding. |
|
9326
|
Amber |
18,000 |
Fixture 1 min
Full 24 hrs |
3,000 |
-65 °F
to
250 °F |
1387 / 1380 |
General - purpose structural
adhesive. Ideal for fast fixturing. Excellent adhesion to wide variety of
surfaces. |
|
9330
|
Amber |
67,000 |
Fixture 5 min
Full 24 hrs |
3,700 |
-65 °F
to
275 °F |
1387 / 1380 |
High performance adhesive with
excellent adhesion to ferrite, metals, ceramics, etc. |
|
9392
|
Amber |
60,000 |
Fixture 60 sec
Full 24 hrs |
3,000 |
-65 °F
to
300 °F |
1387 / 1380 |
Specifically designed for magnet
bonding applications. Fast curing with excellent mechanical properties. |
|
| |
|
Packaging:
These adhesives are available in 10 ml, 50 ml, 250 ml and 1
liter kit. 10 kg packing available upon request. Activators are
available in 4 oz. spray bottle, 1 liter, 1 gallon and 5 gallon
packing. |
|
|
|
