PARTITE® Adhesives for Composite Bonding

Acrylic Adhesives

Acrylic Adhesives are well-known for their durability and strength and usually made from esters of acrylic, methacrylic and cyanoacrylic acids. Acrylic adhesives are used for applications that require high tensile and shear strength with shock and stress resistance.

Some of the main advantages of Acrylic Adhesives are listed below:

  • Quick settling time; almost twice as fast than ordinary Acrylic adhesives
  • Low Odor and hence better working environment
  • High tensile strength even on difficult to bond substrates
  • Optically clear
  • Electrically insulated

PARTITE Acrylic Adhesives are no mix, two-part system. Simply apply Acrylic Adhesives to one surface, the activator to the other and join parts together. Fixture time will range from 60 seconds to 5 minutes depending upon the grade.

Following are the most popular grades with specifications. Custom formulations and variety of packing are available.

Product Color Viscosity,
cps
Cure
Speed
Shear
Strength
(psi)
Temperature
Range
Activator Application
9312
TDS
Amber 1,000 Fixture 30 sec
Full 24 hrs
3,000 -65°F to 225 °F 1387 / 1380 High strength structural adhesive ideally designed for
automotive rearview mirror bonding.
9326
TDS
Amber 18,000 Fixture 1 min
Full 24 hrs
3,000 -65°F to 250 °F 1387 / 1380 General - purpose structural adhesive. Ideal for fast fixturing.
Excellent adhesion to wide variety of surfaces.
9330
TDS
Amber 67,000 Fixture 5 min
Full 24 hrs
3,700 -65°F to 275 °F 1387 / 1380 High performance adhesive with excellent adhesion to
ferrite, metals, ceramics, etc.
9392
TDS
Amber 60,000 Fixture 60 sec
Full 24 hrs
3,000 -65°F to 300 °F 1387 / 1380 Specifically designed for magnet bonding applications.
Fast curing with excellent mechanical properties.

Packaging:
These adhesives are available in 10 ml, 50 ml, 250 ml and 1 liter kit. 10 kg packing available upon request. Activators are available in 4 oz. spray bottle, 1 liter, 1 gallon and 5 gallon packing.
